Shantui Parts SD22 Final drive box (L.H.) 154-27-11113 154-27-11123
Part Name:Final drive box
Part Number: 154-27-11113 154-27-11123
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | |
| SD22,SD22E, | SD22R, | |||
| SD22D | SD22S | |||
| 1 | 154-27-11113 | Final drive box (L.H.) | 1 | 1 |
| 1 | 154-27-11123 | Final drive box (R.H.) | 1 | 1 |
| 2 | 154-27-11130 | Gasket | 2 | 2 |
| 3 | 04020-01842 | Cylindrical pin | 4 | 4 |
| 4 | 07049-12018 | Dust plug | 4 | 4 |
| 5 | 01010-52050 | Bolt | 62 | 62 |
| 6 | 01602-22060 | Washer | 62 | 62 |
| 7 | 154-27-11410 | Plate | 2 | 2 |
| 8 | 175-27-31540 | Lock pad | 4 | 4 |
| 9 | 01010-51220 | Bolt | 8 | 8 |
| 10 | 154-27-15110 | Guard plate (L.H.) | 1 | 1 |
| 10 | 154-27-15120 | Guard plate (R.H.) | 1 | 1 |
| 11 | 01010-52045 | Bolt | 16 | 16 |
| 12 | 01605-12040 | Washer | 16 | 16 |
| 13 | 154-27-12122 | Hub of gear | 2 | |
| 13 | 158-18-00002 | Hub of gear | 2 | |
| 14 | 154-27-12110 | Gear (2nd) | 2 | 2 |
| 15 | 175-27-12181 | Bolt | 32 | 32 |
| 16 | 175-27-12190 | Lock pad | 16 | 16 |
| 17 | 01582-12419 | Nut | 32 | 32 |
| 18 | 150-09-13110 | Cylindrical Roller Bearing | 2 | 2 |
| 19 | 04071-00250 | Retaining ring | 2 | 2 |
| 20 | 170-09-13250 | Bearing | 2 | 2 |
| 21 | 154-27-12560 | Retaining ring | 2 | 2 |
| 22 | 170-27-12210 | Stop washer | 6 | 6 |
| 23 | 01010-51440 | Bolt | 12 | 12 |
| 24 | 154-27-12152 | Cover | 2 | 2 |
| 25 | 154-27-12162 | Cover | 2 | 2 |
| 26 | 07000-15410 | O-ring | 4 | 6 |
| 27 | 01010-51230 | Bolt | 40 | 60 |
| 28 | 01602-21236 | Washer | 40 | 60 |
| 29 | 170-27-12513 | Oil seal,Float | 4 | 4 |
| 30 | 170-27-12520 | O-ring | 4 | 4 |
| 31 | 158-18-01000 | Cover | 2 | |
