Shantui SD22 Steering valve 154-40-00082 144-40-22211
Part Name:Steering valve
Part Number: 154-40-00082 144-40-22211
Machine Model:SD22
| NO. | PART NO. | PART NAME | Q'TY | ODEL | |
| 0 | 154-40-00082 | Steering valve | 1 | ||
| 1 | 144-40-22211 | Valve body | 1 | ||
| 2 | 195-40-11540 | Shaft | 2 | ||
| 3 | 01593-11613 | Nut | 2 | ||
| 4 | 04050-14025 | Cotter pin | 2 | ||
| 5 | 144-40-22180 | Bracket | 2 | ||
| 6 | 144-40-22170 | Bracket | 2 | ||
| 7 | 175-40-31230 | Spring | 2 | ||
| 8 | 04065-03212 | Retaining ring | 2 | ||
| 9 | 195-40-13110 | Retaining ring | 2 | ||
| 10 | 195-40-11550 | Spring | 2 | ||
| 11 | 195-40-11560 | Bracket | 2 | ||
| 12 | 175-40-31150 | Spring | 2 | ||
| 13 | 195-40-11570 | Bracket | 2 | ||
| 14 | 144-40-22190 | Washer | 2 | ||
| 17 | 195-40-11531 | Spool valve | 2 | ||
| 18 | 702-11-11190 | Piston | 2 | ||
| 19 | 175-40-31130 | Spring | 2 | ||
| 20 | 175-40-31530 | Plug | 2 | ||
| 21 | 07002-03034 | O-ring | 2 | ||
| 22 | 07043-50108 | Plug | 1 | ||
| 23 | 144-40-22230 | Valve body | 1 | ||
| 24 | 144-40-22290 | Guide bush | 2 | ||
| 25 | 144-40-22260 | Shaft | 2 | ||
| 26 | 144-40-22270 | Bracket | 2 | ||
| 27 | 144-40-22280 | Bracket | 2 | ||
| 28 | 144-40-22340 | Spring | 2 | ||
| 29 | 154-40-41130 | Spring | 2 | ||
| 30 | 01590-10607 | Nut | 4 | ||
| 31 | 04050-11212 | Cotter pin | 4 | ||
| 32 | 144-40-22311 | Spool valve | 2 | ||
| 33 | 144-40-22320 | Piston | 2 | ||
| 34 | 175-40-31410 | Spring | 2 | ||
| 35 | 144-40-22250 | Plug | 2 | ||
| 36 | 144-40-22330 | Plate | 1 | ||
| 37 | 01010-50816 | Bolt | 1 | ||
| 38 | 01650-20808 | Washer | 1 | ||
| 39 | 175-40-31510 | Tube | 2 | ||
| 40 | 07000-02011 | O-ring | 4 | ||
| 41 | 07000-02015 | O-ring | 1 | ||
| 42 | 01010-51050 | Bolt | 2 | ||
